Pricing Tubular Pile
We are presenting hereunder a calculation of the price. As you can notice one should inform about following parameters mentioned hereaftre:
- Outside diameter (Ø) in mm,
- Wall Thickness (T) in mm
- Yield strength in MPa of the grade
- Average unit lengths and
- Number of piles
- or Total length with
- Coating and
- Interlock height per pile or Total length all in m
Ø = 813 mm
T = 14,2 mm
Steel Grade S 355 / X 52 i.e. 355 MPa
Average unit length 24,3 m
Number of piles 56
or Total Length 1.360,8 m
Average anticorrosion coating 8,55 m or total 478,8 m
Average interlock 16,2 m per side
Calculation of Physical parameters:
Unit weight = (Ø - T) x T x 0,0246615 = 279,66 kg/m
Quantity total weight = 0,27966 x 1.360,8 m = 380,6 ton
Total surface to be coated is 0,813 x ∏ (or 3,14159) x 1.814,4 m = 4.633 m2
Total interlocks supply and weld = 32,4 m per pile x 56 = 1.814,4 m
Total freight = Ø x Ø x Total length = 0,813 x 0,813 x 1.360,8 = 899 cbm
Estimate Steps
Spiral or Long Welded Pipe
700 to 1.700 €/t
1.000 x 380,6 t = 380.600 €
Fabrication (Interlock)
20 to 60 €/m
45x1.814,4 m=81.648 €
Anti-corrosion Painting
10 to 60 €/m2
20 x 4.633 m2
= 92.660 €
Trucking < 23 t
200 to 3.500 €/truck
56/3=18,6 or 19 trucks
500 x 19 = 9.500 €
Continued —>
Handling and storage
10 to 40 €/t
10 x 390 t = 3.900 €
Load out export port
15 to 50 €/t
20 x 390 t = 7.800 €
Maritime freight liner out or free out
30 to 180 €/m3
65 x 899 m3 = 58.435 €
Discharging import port
10 to 60 €/t
35 x 390 t = 13.650 €
TOTAL 654.193 €
excluding custom clearance, VAT, eventual import duties, storage and trucking to site if any
